Lesson 9

Linear Models

9.1: Candlelight (10 minutes)

Warm-up

In this warm-up, students work with data to determine if the situation represented by the data could be modeled by a linear function (MP4). Students are given 3 different data points and use what they know about linear functions and proportional relationships to estimate when the candle will burn out. Students are then asked to determine if this situation could be modeled by a linear function. The focus of the discussion should be around the last question and how students justify their reasoning.

Launch

Arrange students in groups of 2. Give students 1–2 minutes of quiet work time and ask them to pause after the first question. Poll the class for their response to the first question, and display the range of responses for all to see. Then, ask them to continue and discuss their response to the second question with their partner. If they don't agree, partners should work to understand each other’s thinking. Follow with a whole-class discussion.

If using the digital activity, follow the structure above, as the prompts are the same. However, the digital activity allows students to plot points quickly without having to set up the axes from scratch. This means students may conclude the graph is not quite linear purely from a visual. Make sure these students can explain and understand their peers’ rationale in answering the questions using more than just the plotted points. If any students attempt to guess a linear equation that fits the data, ask them to share during the discussion.

Student Facing

A candle is burning. It starts out 12 inches long. After 1 hour, it is 10 inches long. After 3 hours, it is 5.5 inches long.

  1. When do you think the candle will burn out completely?
  2. Is the height of the candle a function of time? If yes, is it a linear function? Explain your thinking.

This tool is here for you to use if you choose. To plot a point, type its coordinates. For example, try typing \((1,2)\). To graph a line, type its equation. Try typing \(y=2x-3\). You can delete anything by clicking on the X next to it.

Student Response

For access, consult one of our IM Certified Partners.

Launch

Arrange students in groups of 2. Give students 1–2 minutes of quiet work time and ask them to pause after the first question. Poll the class for their response to the first question, and display the range of responses for all to see. Then, ask them to continue and discuss their response to the second question with their partner. If they don't agree, partners should work to understand each other’s thinking. Follow with a whole-class discussion.

If using the digital activity, follow the structure above, as the prompts are the same. However, the digital activity allows students to plot points quickly without having to set up the axes from scratch. This means students may conclude the graph is not quite linear purely from a visual. Make sure these students can explain and understand their peers’ rationale in answering the questions using more than just the plotted points. If any students attempt to guess a linear equation that fits the data, ask them to share during the discussion.

Student Facing

A candle is burning. It starts out 12 inches long. After 1 hour, it is 10 inches long. After 3 hours, it is 5.5 inches long.

  1. When do you think the candle will burn out completely?
  2. Is the height of the candle a function of time? If yes, is it a linear function? Explain your thinking.

Student Response

For access, consult one of our IM Certified Partners.

Activity Synthesis

The purpose of this discussion is for students to justify how this situation can be modeled by a linear equation. Select students who answered yes to the last question and ask:

  • “Was the data exactly linear? If not, what made you decide that you could treat it as such?”
  • “Which data points did you use to predict when the candle would burn out?”
  • “What was the slope between the first two data points? What was the slope between the last two data points? What does it mean that their slopes are different?”

Tell students that although the data is not precisely linear, it does makes sense to model the data with a linear function because the points resemble a line when graphed. We can then use different data points to help predict when the candle would burn out. Answers might vary slightly, but it results in a close approximation.

Conclude the discussion by asking students to reconsider the range of values posted earlier for the first question and ask if they think that range is acceptable or if it needs to change (for example, students may now think the range should be smaller after considering the different slopes).

9.2: Shadows (10 minutes)

Activity

The purpose of this activity is for students to determine if a given set of data can be modeled by a linear function. Students first view a set of pictures and data for the length of a shadow at 0, 20, and 60 minutes. Then, they make a prediction about how long a shadow will be after 95 minutes. Students then compare their estimate with the actual length of the shadow and make conclusions about the model they used to make their estimate.

Monitor for students using different strategies to make their prediction. For example, students may use different pairs of points to make their prediction or they may try to use all three. The discussion for this activity focuses on how, if we are given two input-output pairs, we can always find a linear function with these inputs and outputs, but that doesn’t mean a linear function is actually appropriate for the situation. In this case, we can see when we get more data that a linear function is not appropriate.

Launch

Arrange students in groups of 2. Tell students to close their books or devices, and display the image and given data for all to see. Give students 1–2 minutes of quiet think time to estimate the length of the shadow after 95 minutes and discuss their responses with their partner. Encourage partners to discuss their estimation strategy and why their estimate makes sense. Invite groups to share their estimate and reasoning with the whole class.

Tell students to open their books or devices and give work time for the remaining questions. Follow with a whole-class discussion.

If using the digital activity, follow the directions above. In this lesson, the digital activity allows students to plot their points and test their thinking with a dynamic applet, however, the mathematics is truly the same.

Engagement: Develop Effort and Persistence. Encourage and support opportunities for peer interactions. Display sentence frames to support students when they explain their estimation with their partner. For example, “I predict _____ because . . .” and “How did you get . . .?”
Supports accessibility for: Language; Social-emotional skills
Reading, Speaking, Listening: MLR6 Three Reads. Use this routine to support reading comprehension without solving for students. In the first read, students read the problem and review the images with the goal of comprehending the situation (e.g., a photo of a stick’s shadow was taken at different times; the length of the shadow was different at different times). In the second read, identify the important quantities by asking students what can be counted or measured (e.g., at 20 minutes, the shadow was 10.5 cm long; at 60 minutes, the shadow was 26 cm long). After the third read, ask students to brainstorm possible strategies to complete the task. This will help students connect the language in the problem and the reasoning needed to solve the problem, while keeping the intended level of cognitive demand in the task.
Design Principle(s): Support sense-making

Student Facing

When the Sun was directly overhead, the stick had no shadow. After 20 minutes, the shadow was 10.5 cm long. After 60 minutes, it was 26 cm long.

Three photos of a sidewalk and a stick. Frist, there is no shadow on the sidewalk. Second there is a short, horizontal shadow on the sidewalk. Third, there is a long horizontal shadow on the sidewalk.
  1. Based on this information, estimate how long it will be after 95 minutes.
  2. After 95 minutes, the shadow measured 38.5 cm. How does this compare to your estimate?
  3. Is the length of the shadow a function of time? If so, is it linear? Explain your reasoning.

This tool is here for you to use if you choose. To plot a point, type its coordinates. For example, try typing \((3,5)\). To graph a line, type its equation. Try typing \(y=2x+7\). You can delete anything by clicking on the X next to it.

Student Response

For access, consult one of our IM Certified Partners.

Launch

Arrange students in groups of 2. Tell students to close their books or devices, and display the image and given data for all to see. Give students 1–2 minutes of quiet think time to estimate the length of the shadow after 95 minutes and discuss their responses with their partner. Encourage partners to discuss their estimation strategy and why their estimate makes sense. Invite groups to share their estimate and reasoning with the whole class.

Tell students to open their books or devices and give work time for the remaining questions. Follow with a whole-class discussion.

If using the digital activity, follow the directions above. In this lesson, the digital activity allows students to plot their points and test their thinking with a dynamic applet, however, the mathematics is truly the same.

Engagement: Develop Effort and Persistence. Encourage and support opportunities for peer interactions. Display sentence frames to support students when they explain their estimation with their partner. For example, “I predict _____ because . . .” and “How did you get . . .?”
Supports accessibility for: Language; Social-emotional skills
Reading, Speaking, Listening: MLR6 Three Reads. Use this routine to support reading comprehension without solving for students. In the first read, students read the problem and review the images with the goal of comprehending the situation (e.g., a photo of a stick’s shadow was taken at different times; the length of the shadow was different at different times). In the second read, identify the important quantities by asking students what can be counted or measured (e.g., at 20 minutes, the shadow was 10.5 cm long; at 60 minutes, the shadow was 26 cm long). After the third read, ask students to brainstorm possible strategies to complete the task. This will help students connect the language in the problem and the reasoning needed to solve the problem, while keeping the intended level of cognitive demand in the task.
Design Principle(s): Support sense-making

Student Facing

When the Sun was directly overhead, the stick had no shadow. After 20 minutes, the shadow was 10.5 cm long. After 60 minutes, it was 26 cm long.

Three photos of a sidewalk and a stick. Frist, there is no shadow on the sidewalk. Second there is a short, horizontal shadow on the sidewalk. Third, there is a long horizontal shadow on the sidewalk.
  1. Based on this information, estimate how long it will be after 95 minutes.
  2. After 95 minutes, the shadow measured 38.5 cm. How does this compare to your estimate?
  3. Is the length of the shadow a function of time? If so, is it linear? Explain your reasoning.

Student Response

For access, consult one of our IM Certified Partners.

Activity Synthesis

Select groups that had different strategies for making their original prediction to share their reasoning about whether or not a linear model is a good fit for predicting the length of the shadow. In particular, make sure it is pointed out how much using the rate of change determined by the first two points over-predicts the length of the shadow after 95 minutes.

Tell students that if we only use two data points, it is always possible to model a situation with a linear function. We need additional data to help us determine if a linear model is appropriate. In this case, mathematicians have also used the geometry of Earth traveling around the Sun to provide a better model for the length of the shadow as a function of time that is not a linear function.

9.3: Recycling (10 minutes)

Activity

The purpose of this activity is for students to approximate different parts of a graph with an appropriate line segment. This graph is from a previous activity, but students interact with it differently by sketching a linear function that models a certain part of the data. They take this model and consider its ability to predict input and output for other parts of the graph. This helps students think about subsets of data that might have different models from other parts of the data.

Identify students who draw in different lines for the first question to share during the Activity Synthesis.

Teacher Notes for IM 6–8 Math Accelerated
Due to how lessons and units are arranged in IM 6–8 Math Accelerated, students learn about scatter plots prior to this lesson instead of after this lesson. Be prepared to clarify that the graph shown in this activity is a time plot and not a scatter plot, and similar to the non linear scatter plots they encountered previously, a single line may not be a good fit for the entire data set.

Launch

Arrange students in groups of 2. Provide students with access to straightedges. Give students 3–5 minutes of quiet work time and then time to share their responses with their partner. Follow with a whole-class discussion.

Student Facing

In an earlier lesson, we saw this graph that shows the percentage of all garbage in the U.S. that was recycled between 1991 and 2013.

A photo of recycling bins.
A scatterplot, horizontal, year, 1900 to 2015 by fives, vertival, percentage recycled, 15 % to 27 % by threes.
  1. Sketch a linear function that models the change in the percentage of garbage that was recycled between 1991 and 1995. For which years is the model good at predicting the percentage of garbage that is produced? For which years is it not as good?
  2. Pick another time period to model with a sketch of a linear function. For which years is the model good at making predictions? For which years is it not very good?

Student Response

For access, consult one of our IM Certified Partners.

Activity Synthesis

The purpose of this discussion is for students to understand that although you might find a good model for one part of a graph, that does not mean that model will work for other parts.

Select students previously identified to share their models. Display these for all to see throughout the entire discussion. Questions for discussion:

  • “How much does your model for 1991 to 1995 overestimate 1996? 1997?”
  • “If we drew in a single line to model 1997 to 2013, what would that line predict well? What would that line predict poorly?” (A single line modeling those years would reasonably predict the percent recycled from 1997 to 2010, but it wouldn’t be able to show how the percent recycled from 2011 to 2013 is decreasing.)

Conclude the discussion by telling students that there is a trade-off in number of years to include in the interval and accuracy. We could “connect the dots” and be accurate about everything, but then our model has limited use and is complicated with so many parts. (Just imaging writing an equation for each piece!)

Speaking: MLR8 Discussion Supports. Use this routine to support whole-class discussion. For each model that is shared, ask students to summarize what they heard using mathematical language. Consider providing students time to restate what they hear to a partner, before selecting one or two students to share with the class. Ask the original speaker if their peer was accurately able to restate their thinking. Call students' attention to any words or phrases that helped to clarify the original statement. This will provide more students with an opportunity to speak, and better understand each model.
Design Principle(s): Support sense-making

Lesson Synthesis

Lesson Synthesis

Tell students that a mathematical model is a mathematical object like an equation, a function, or a geometric figure that we use to represent a real-life situation. Sometimes a situation can be modeled by a linear function. We have to use judgment about whether this is a reasonable thing to do based on the information we are given. We must also be aware that the model makes imprecise predictions, or may only be appropriate for certain ranges of values.

Give students 1–2 minutes to think of a situation that may seem linear but actually is not. Invite them to share their situations. For example, the height of humans may look linear for short periods of time, but eventually growth stops, so we wouldn’t want to use a linear model for height over a large period of time.

9.4: Cool-down - Board Game Sales (5 minutes)

Cool-Down

For access, consult one of our IM Certified Partners.

Student Lesson Summary

Student Facing

Water has different boiling points at different elevations. At 0 m above sea level, the boiling point is \(100^\circ\) C. At 2,500 m above sea level, the boiling point is 91.3\(^\circ\) C. If we assume the boiling point of water is a linear function of elevation, we can use these two data points to calculate the slope of the line: \(\displaystyle m=\frac{91.3-100}{2,\!500-0}=\frac{\text-8.7}{2,\!500}\)

This slope means that for each increase of 2,500 m, the boiling point of water decreases by \(8.7^\circ\) C. Next, we already know the \(y\)-intercept is \(100^\circ\) C from the first point, so a linear equation representing the data is \(\displaystyle y=\frac{\text-8.7}{2,\!500}x+100\)

This equation is an example of a mathematical model. A mathematical model is a mathematical object like an equation, a function, or a geometric figure that we use to represent a real-life situation. Sometimes a situation can be modeled by a linear function. We have to use judgment about whether this is a reasonable thing to do based on the information we are given. We must also be aware that the model may make imprecise predictions, or may only be appropriate for certain ranges of values.

Testing our model for the boiling point of water, it accurately predicts that at an elevation of 1,000 m above sea level (when \(x=1,\!000\)), water will boil at \(96.5^\circ\) C since \(y=\frac{\text-8.7}{2,\!500}\boldcdot 1000+100=96.5\). For higher elevations, the model is not as accurate, but it is still close. At 5,000 m above sea level, it predicts \(82.6^\circ\) C, which is \(0.6^\circ\) C off the actual value of \(83.2^\circ\) C. At 9,000 m above sea level, it predicts \(68.7^\circ\) C, which is about \(3^\circ\) C less than the actual value of \(71.5^\circ\) C. The model continues to be less accurate at even higher elevations since the relationship between the boiling point of water and elevation isn’t linear, but for the elevations in which most people live, it’s pretty good.
