Lesson 11

Domain and Range (Part 2)

11.1: Which One Doesn't Belong: Unlabeled Graphs (5 minutes)

Warm-up

This warm-up prompts students to carefully analyze and compare the properties of four graphs. Each graph represents a function, but no labels or scales are shown on the coordinate axes, so students need to look for and make use of the structure of the graphs in determining how each one is like or unlike the others (MP7).

In making comparisons, students have a reason to use language precisely (MP6), especially mathematical terms that describe features of graphs or properties of functions.

Student Facing

Which one doesn't belong?

A

A graph with origin O. The graph is a line crossing the vertical axis and slants downward to cross the horizontal axis.

B

A graph.

C

A graph with origin O. The graph is a horizontal line passing through the middle of the vertical axis.

D

A graph.

Student Response

Student responses to this activity are available at one of our IM Certified Partners

Activity Synthesis

Ask each group to share one reason why a particular item does not belong. Record and display the responses for all to see. Encourage students to use relevant mathematical vocabulary in their explanations, and ask students to explain the meaning of any terminology that they do use, such as "intercepts," "minimum," or "linear functions."

After each response, ask the class if they agree or disagree. Since there is no single correct answer to the question of which one does not belong, attend to students’ explanations and ensure the reasons given are correct.

By now students are well aware that certain features of a graph have special significance in that they tell us something about the quantities or relationships in the situation. Tell students that features of graphs can also help us understand the domain and range of a function. We will explore this in the lesson.

11.2: Time on the Swing (20 minutes)

Activity

In this activity, students are given the same four graphs they saw in the warm-up and four descriptions of functions and are asked to match them. All of the functions share the same context. Students then use these features to reason about likely domain and range of each function.

To make the matches, students analyze and interpret features of the graphs, looking for and making use of structure in the situation and in the graphs (MP7). Here are some possible ways students may reason about each match:

  • The swing goes up and down while the child is swinging, so D could be a graph for function \(h\).
  • The time left on the swing decreases as the time on the swing increases, so A is a possible graph for function \(r\).
  • The distance of the child from the top beam of the swing doesn't change as long as the child is on the swing, so C is a possible graph for function \(d\).
  • The total number of times the swing is pushed must be a counting number and cannot be fractional. Graph B has multiple pieces and each one could represent the total number of push for certain intervals of time, so B is a possible graph of \(s\).

Students reason quantitatively and abstractly as they connect verbal and graphical representations of functions and as they think about the domain and range of each function (MP2).

Launch

Ask students to imagine a child getting on a swing, swinging for 30 seconds, and then getting off the swing. Explain that they will look at four functions that can be found in this situation. Their job is to match verbal descriptions and graphs that define the same functions, and then to think about reasonable domain and range for each function. Tell students they will need additional information for the last question.

Arrange students in groups of 2. Give students a few minutes of quiet time to think about the first two questions, and then time to discuss their thinking with their partner. Follow with a whole-class discussion.

Invite students to share their matching decisions and explanations as to how they know each pair of representations belong together. Make sure that students can offer an explanation for each match, including for their last pair (other than because the description and the graph are the only pair left). See some possible explanations in the Activity Narrative.

Next, ask students to share the points that they think would be helpful for determining the domain and range of each function. If students gesture to the intercepts, a maximum, or a minimum on a graph but do not use those terms to refer to points, ask them to use mathematical terms to clarify what they mean.

Here is the information students will need for the last question. Display it for all to see, or provide it as requested. If the requested information is not shown or cannot be reasoned from what is available, ask students to request a different piece of information.

  • The child is given 30 seconds on the swing.
  • While the child is on the swing, an adult pushes the swing a total of 5 times.
  • The swing is 1.5 feet (18 inches) above ground.
  • The chains that hold the seat and suspend it from the top beam are 7 feet long.
  • The highest point that the child swings up to is 4 feet above the ground.

If time is limited, ask each partner to choose two functions (different than their partner's) and write the domain and range only for those functions.

Speaking, Representing: MLR8 Discussion Supports. Use this routine to support whole-class discussion as students explain how they matched the function description to the graph. Display the following sentence frames for all to see: “_____ matches the graph _____ because . . .” and “I noticed _____, so . . . .” Encourage students to challenge each other when they disagree. The student frames will help students consider the domain and range of functions as they connect written descriptions with graphical representations.
Design Principle(s): Support sense-making
Representation: Internalize Comprehension. Use color coding and annotations to highlight connections between representations in a problem. For example, invite students to highlight the input in each description using one color, label the horizontal axis of each graph, and highlight the label in the same color. Then they can repeat the process for the outputs and the vertical axes.
Supports accessibility for: Visual-spatial processing

Student Facing

A child gets on a swing in a playground, swings for 30 seconds, and then gets off the swing.

  1. Here are descriptions of four functions in the situation and four graphs representing them.

    The independent variable in each function is time, measured in seconds.

    A girl on a swing.

    Match each function with a graph that could represent it. Then, label the axes with the appropriate variables. Be prepared to explain how you make your matches.

    • Function \(h\): The height of the swing, in feet, as a function of time since the child gets on the swing
    • Function \(r\): The amount of time left on the swing as a function of time since the child gets on the swing
    • Function \(d\): The distance, in feet, of the swing from the top beam (from which the swing is suspended) as a function of time since the child gets on the swing
    • Function \(s\): The total number of times an adult pushes the swing as a function of time since the child gets on the swing

    A

    A graph with origin O. The graph is a line crossing the vertical axis and slants downward to cross the horizontal axis.

    B

    A graph.

    ​​​​​​

    C

    A graph with origin O. The graph is a horizontal line passing through the middle of the vertical axis.

    D

    A graph.
  2. On each graph, mark one or two points that—if you have the coordinates—could help you determine the domain and range of the function. Be prepared to explain why you chose those points.
  3. Once you receive the information you need from your teacher, describe the domain and range that would be reasonable for each function in this situation.

Student Response

Student responses to this activity are available at one of our IM Certified Partners

Anticipated Misconceptions

Some students may struggle to match the descriptions and the graphs because they confuse the independent and dependent variables and think that, in each situation, time is represented by the vertical axis. Encourage them to re-read the activity statement, clarify the input and output in each situation, label the horizontal graph with the input, and then try interpreting the graphs again.

Activity Synthesis

Select students to share the domain and range for each function and their reasoning. Record and display their responses for all to see.

One key point to highlight is that the range of a function could be a single value (say 7, as shown in graph C), a bunch of isolated values (say, only some whole numbers, as shown in graph B), all values in an interval (say, all values from 1.5 to 4, as shown in graph D, or all values between 0 and 30, as in graph A), or a combination of these.

The domain of a function may also be limited in similar ways. Tell students that, in upcoming lessons, we will look at functions in which the rules relating their input and output are a bit more complex, so their domain and range are also a bit more so.

11.3: Back to the Bouncing Ball (10 minutes)

Activity

In this activity, students continue to interpret a graph of a function in terms of a situation and relate the features of the graph to the domain and range of the function. The context is a familiar one, allowing students to focus their reasoning on domain and range.

Unlike in the activity about a child on a swing, the graph includes a scale on each axis and the coordinate pairs of some points, allowing students to identify the range more definitively. On the other hand, the graph is a partial representation of the function, as it does not show what happens after a dropped ball hits the ground the fifth time. When describing the domain, students need to attend to what is reasonable in this situation (that is, noting that the ball likely does not just stop after the fifth bounce).

Student Facing

A tennis ball was dropped from a certain height. It bounced several times, rolled along for a short period, and then stopped. Function \(H\) gives its height over time.

Here is a partial graph of \(H\). Height is measured in feet. Time is measured in seconds.

Use the graph to help you answer the questions.

Be prepared to explain what each value or set of values means in this situation.

Nonlinear function. Time (seconds) and height (feet).
  1. Find \(H(0)\).
  2. Solve \(H(x) = 0\).
  3. Describe the domain of the function.
  4. Describe the range of the function.

Student Response

Student responses to this activity are available at one of our IM Certified Partners

Student Facing

Are you ready for more?

In function \(H\), the input was time in seconds and the output was height in feet.

Think about some other quantities that could be inputs or outputs in this situation.

  1. Describe a function whose domain includes only integers. Be sure to specify the units.
  2. Describe a function whose range includes only integers. Be sure to specify the units.
  3. Sketch a graph of each function.
    A blank graph. Origin O.
    A blank graph. Origin O.

Student Response

Student responses to this activity are available at one of our IM Certified Partners

Activity Synthesis

Focus the discussion on how students reasoned about the domain and the range for the function. Highlight explanations that account for what is realistic in the context.

  • The domain tells us all the possible amounts of time that passed since the moment the tennis ball was dropped until it stopped rolling.
  • The range includes all the possible heights of the tennis ball from the time it was dropped until the time it stopped rolling.

Ask students if there are points on the graph whose coordinates are particularly useful for identifying the domain and range of the function. (The heights of the bounces? The points where the ball hits the ground? Points between the two? Others?)

Emphasize that, just like in the activity about the swing, some points and features on a graph can give us more information than others about possible input-output values of a function.

Speaking, Listening, Representing: MLR8 Discussion Supports. Use this routine to support whole-class discussion of the meaning of domain and range in the context of a tennis ball bouncing. As students share explanations of their reasoning about the domain and the range for the function, encourage students to press for details and precision in language in peers’ responses by asking questions such as, “Can you explain this using points on the graph?” or “Are there values for the domain and range not shown on the graph? How do you know?”
Design Principle(s): Optimize output (for explanation); Cultivate conversation

Lesson Synthesis

Lesson Synthesis

Display several familiar graphs of functions from this unit. Here are some examples.

A graph.
2 graphs. Horizontal axis, 0 to 7, time in seconds. Vertical axis, 0 to 50 by 10’s, height in meters. Graph R is a parabolic and opens down. Graph D is piecewise linear.
piecewise function
squiggly line graphing distance from post over time

Ask students to examine the graphs and use them to help summarize what graphs can tell us about the domain and range of functions. Ask students to complete the following prompts as thoroughly as they can.

  • I can learn about the domain and range of a function from a graph by looking for . . .
  • A graph may not always show all that is needed to fully describe the domain and range, however. For example, it may not show . . .

11.4: Cool-down - A Pot of Water (5 minutes)

Cool-Down

Cool-downs for this lesson are available at one of our IM Certified Partners

Student Lesson Summary

Student Facing

The graph of a function can sometimes give us information about its domain and range.

Here are graphs of two functions we saw earlier in the unit. The first graph represents the best price of bagels as a function of the number of bagels bought. The second graph represents the height of a bungee jumper as a function of seconds since the jump began.

What are the domain and range of each function?

The number of bagels cannot be negative but could include 0 (no bagels bought). The domain of the function therefore includes 0 and positive whole numbers, or \(n \geq 0\).

The best price can be \$0 (for buying 0 bagels), certain multiples of 1.25, certain multiples of 6, and so on. The range includes 0 and certain positive values.

A graph.

The domain of the height function would include any amount of time since the jump began, up until the jump is complete. From the graph, we can tell that this happened more than 70 seconds after ​​​​​​the jump began, but we don't know the exact value of \(t\).

The graph shows a maximum height of 80 meters and a minimum height of 10 meters. We can conclude that the range of this function includes all values that are at least 10 and at most 80.

A graph.
