Lesson 5

Normal Distributions

  • Let’s investigate a specific type of distribution called a normal distribution.

5.1: Body Temperature

Each histogram represents a group of 500 healthy people who had their temperature taken. Three histograms represent examples of data that approximate a normal distribution and three histograms represent non-examples, or data that do not approximate a normal distribution. What do you think the elements are of a definition of normal distribution?

Examples:

Histogram.
Histogram.
Histogram.

Non-examples:

Histogram.
Histogram.
Histogram.

5.2: Playing a Piano

two raised hands on white background

On many piano keyboards, the distance from one white key to the next is 2.39 centimeters. How many of your classmates could reach two notes that are 9 keys apart (21.5 cm) on a keyboard using only one hand?

  1. Stretch your fingers apart as wide as you can and measure the farthest distance from your thumb to smallest finger. Round your measurement to the nearest tenth of a centimeter.
  2. Your teacher will collect the measurements from the class. Draw a dot plot or histogram from the class data.
    A blank graph. The horizontal axis, labeled handspan, centimeters, ranges from 16 to 25.5 by 0.5’s. The vertical axis ranges from 0 to 10, by ones.
  3. Describe the distribution you drew using terms such as: symmetric, approximately symmetric, skewed left, skewed right, approximately uniform, uniform, bell-shaped, or bimodal. Estimate the center of your distribution.
  4. How would you use your distribution to determine how many people in the class can reach the two notes 9 keys apart?

5.3: Relative Frequency Distribution

Manufacturers of butter make sticks of butter that weigh 110 grams on average. A manufacturer suspects the machine that forms the sticks of butter may have a problem, so they weigh each stick of butter the machine produces in an hour.

The weights are grouped into intervals of 0.5 grams and are summarized in a frequency table.



weight (grams) frequency relative frequency
107–107.5 5
107.5–108 17
108–108.5 52
108.5–109 118
109–109.5 172
109.5–110 232
110–110.5 219
110.5–111 172
111–111.5 95
111.5–112 57
112–112.5 23
112.5–113 8
113–113.5 1
total 1,171

The same data are summarized in this histogram.



Histogram.

​​​​​

Although this information is useful, it might be more helpful to know the proportion of sticks of butter in each weight interval rather than the actual number of sticks in that weight interval.

  1. Complete the table by dividing each frequency value by the total number of sticks of butter in the data set. Round each value to 4 decimal places.
  2. A relative frequency histogram is a histogram in which the height of each bar is the relative frequency. Since the heights of the bars are found by dividing each height by the total number of sticks of butter, the shape of the distribution is the same as a regular histogram, but the labels on the \(y\)-axis are changed. Label the \(y\)-axis with the correct values for each mark.
    Histogram.
  3. The manufacturer believes they should replace the machine if more than 25% of the sticks of butter are more than 1 gram away from the intended value of 110 grams.
    1. Indicate on the relative frequency histogram the bars that correspond to sticks of butter that are more than 1 gram away from the intended weight of a stick of butter.
    2. Should this machine be replaced? Explain or show your reasoning.

5.4: The Normal Curve

These curves represent normal distributions with different means and standard deviations. What do you notice?

mean = 10. standard deviation = 1

A bell-shaped distribution.

mean = 10. standard deviation = 2

A bell-shaped distribution.

mean = 8. standard deviation = 2

A bell-shaped distribution.

mean = 12. standard deviation = 1

A bell-shaped distribution.

mean = 10. standard deviation = 0.8

A bell shaped distribution.


The equation for the curve for a normal distribution is

\(f(x) = \frac{1}{\sigma \sqrt{2\pi}} \boldcdot e^{\frac{-(x-\mu)^2}{2\sigma^2}}\)

where \(\sigma\) is the standard deviation, \(\mu\) is the mean, and \(e\) is a particular number close to 2.718.

Notice the part of the function that is \((x - \mu)\). Using your understanding of transformations of functions, how does changing \(\mu\) affect the graph of the function?

Summary

A histogram shows the number of items in the data set that fall into specified intervals. A relative frequency histogram shows the proportion of the entire data set that falls into specified intervals.

For example, a study measured the handspan of 1,000 adults in centimeters. A handspan is the distance from the thumb to the smallest finger when the fingers are stretched out as much as possible. A histogram shows the number of people whose handspans are in certain intervals. The height of each bar in a histogram represents the frequency for the corresponding interval. In this example, there are 132 adults in the study whose handspans are at least 20 centimeters, but less than 20.5 centimeters.

Histogram.

A histogram that uses the relative frequencies shows a distribution with the same shape, but the heights of the bars represent the relative frequency for the corresponding intervals. For example, out of all the adults in the study, 13.2% have handspans that are at least 20 centimeters, but less than 20.5 centimeters (since \(\frac{132}{1,000} = 0.132\)).

Histogram.

In a similar way to how we can model data in a scatter plot with a line or other curve so that additional information can be estimated or predicted, it can be useful to model an approximately symmetric and bell-shaped distribution with a particular distribution called the normal distribution. A normal distribution is symmetric and bell-shaped, has an area of 1 between the \(x\)-axis and the curve, and has the \(x\)-axis as a horizontal asymptote. A normal distribution is determined entirely by the mean and standard deviation.

For the handspan data, the mean is 20.9 cm and the standard deviation is 1.41. The curve that represents the normal distribution with this same mean and standard deviation is shown on top of the relative frequency histogram for the actual data. Notice that the curve does a fairly good job of modeling the actual data in this situation, although it is not perfect.

Histogram with bell curve.

Glossary Entries

  • normal distribution

    mean = 10. standard deviation = 1

    A bell-shaped distribution.

    mean = 10. standard deviation = 2

    A bell-shaped distribution.

    mean = 8. standard deviation = 2

    A bell-shaped distribution.

    A specific distribution in statistics whose graph is symmetric and bell-shaped, has an area of 1 between the \(x\)-axis and the graph, and has the \(x\)-axis as a horizontal asymptote.

  • relative frequency histogram
    Histogram.

    A histogram where the height of each bar is the fraction of the entire data set that falls into the corresponding interval (that is, it is the relative frequency with which the data values fall into that interval).
