Lesson 8

Interpreting and Creating Graphs

Let’s sketch graphs to represent situations.

8.1: Which One Doesn't Belong: Temperature Over Time

Which graph doesn’t belong?

A

A graph, origin O. Horizontal axis is labeled time. Vertical axis is labeled temperature. A horizontal line is drawn on the graph.

B

A graph, origin O. Horizontal axis is labeled time. Vertical axis is labeled temperature. The curve is shaped like a U and opens downward.

C

A graph.

D

A graph.



8.2: Flag Raising (Part 1)

A flag ceremony is held at a Fourth of July event. The height of the flag is a function of time.

Here are some graphs that are each a possible representation of the function.

a US flag being raised

A

A graph.

B

A graph.

C

A graph.

D

A graph.

E

A graph.

F

A graph.
    1. For each graph assigned to you, explain what it tells us about the flag.
    2. Decide as a group which graph(s) appear to be most realistic and which ones least realistic.
  1. Here is another graph that relates time and height.

    A graph.
    1. Can this graph represent the time and height of the flag? Explain your reasoning.
    2. Is this a graph of a function? Explain your reasoning.


Suppose an ant is moving at a rate of 1 millimeter per second and keeps going at that rate for a long time.

If time, \(x\), is measured in seconds, then \(y\), the distance the ant has traveled in millimeters, is \(y=1x\). If time, \(x\), is measured in minutes, the distance in millimeters is \(y=60x\).

  1. Explain why the equation \(y=(365 \boldcdot 24 \boldcdot 3,\!600)x\) gives the distance traveled in millimeters over time, \(x\), measured in years.
  2. Here is a graph of the equation.

    1. Label the axes with appropriate quantities and units.
    2. Does the graph look like that of a function? Why do you think it looks this way?
  3. Adjust the graphing window until the graph no longer looks this way. If you manage to do so, describe the graphing window that you use.
  4. Do you think the last graph in the flag activity could represent a function relating time and height of flag? Explain your reasoning.

8.3: Flag Raising (Part 2)

Your teacher will show a video of a flag being raised. Function \(H\) gives the height of the flag over time. Height is measured in feet. Time is measured in seconds since the flag is fully secured to the string, which is when the video clip begins.

  1. On the coordinate plane, sketch a graph that could represent function \(H\). Be sure to include a label and a scale for each axis.
    A blank graph with grid, origin O. The horizontal axis contains 13 units, beginning at 0. The vertical axis contains 8 units, beginning at 0.
  2. Use your graph to estimate the average rate of change from the time the flag starts moving to the time it stops. Be prepared to explain what the average rate of change tells us about the flag.

8.4: Two Pools

To prepare for a backyard party, a parent uses two identical hoses to fill a small pool that is 15 inches deep and a large pool that is 27 inches deep.

The height of the water in each pool is a function of time since the water is turned on.

Two pools.

Here are descriptions of three situations. For each situation, sketch the graphs of the two functions on the same coordinate plane, so that \(S(t)\) is the height of the water in the small pool after \(t\) minutes, and \(L(t)\) is the height of the water in the large pool after \(t\) minutes.

In both functions, the height of the water is measured in inches.

  • Situation 1: Each hose fills one pool at a constant rate. When the small pool is full, the water for that hose is shut off. The other hose keeps filling the larger pool until it is full.
A blank graph, origin O. Horizontal axis, time in minutes, scale from 0 to 20 by 2s. Vertical axis, height in inches, from 0 to 30 by 3s.
  • Situation 2: Each hose fills one pool at a constant rate. When the small pool is full, both hoses are shut off.
A blank graph, origin O. Horizontal axis, time in minutes, scale from 0 to 20 by 2s. Vertical axis, height in inches, from 0 to 30 by 3s.
  • Situation 3: Each hose fills one pool at a constant rate. When the small pool is full, both hoses are used to fill the large pool until it is full.
A blank graph, origin O. Horizontal axis, time in minutes, scale from 0 to 20 by 2s. Vertical axis, height in inches, from 0 to 30 by 3s.



8.5: The Bouncing Ball

Your teacher will show you one or more videos of a tennis ball being dropped. Here are some still images of the situation.

The height of the ball is a function of time. Suppose the height is \(h\) feet, \(t\) seconds after the ball is dropped.

  1. Use the blank coordinate plane to sketch a graph of the height of the tennis ball as a function of time.

    To help you get started, here are some pictures and a table. Complete the table with your estimates before sketching your graph.

    0 seconds

    A man dropping a ball.

    0.28 seconds

    A man dropping a ball.

    0.54 seconds

    A man dropping a ball.

    0.74 seconds

    A man dropping a ball.

    1.03 seconds

    A man dropping a ball.

    1.48 seconds

    A man dropping a ball.

    1.88 seconds

    A man dropping a ball.

    2.25 seconds

    A man dropping a ball.
    time
    (seconds)
    height
    (feet)
    0
    0.28
    0.54
    0.74
    1.03
    1.48
    1.88
    2.25
    A blank graph, origin O. Horizontal axis, time, seconds, scale from 0 to 4 by 0.25’s. Vertical axis, height, feet, from 0 to 7 by 0.5’s.
  2. Identify horizontal and vertical intercepts of the graph. Explain what the coordinates tell us about the tennis ball.
  3. Find the maximum and minimum values of the function. Explain what they tell us about the tennis ball.


If you only see the still images of the ball and not the video of the ball bouncing, can you accurately graph the height of the ball as a function of time? Explain your reasoning.

Summary

We can use graphs to help visualize the relationship between quantities in a situation, even if we only have a general description.

Here is a description of a hiker’s journey on a trail:

A hiker walked briskly and steadily for about 30 minutes and then took a 10-minute break. Afterward, she jogged all the way to the end of the trail, which took about 20 minutes. There, she took a 15-minute break, and then started walking back leisurely, stopping twice to enjoy the scenery. Her return trip along the same trail took 105 minutes.

We can sketch a graph of the distance the hiker has traveled as a function of time based on this description.

A graph.

Even though we don’t know the specific distances she has traveled or the length of the trail, we can show in the graph some important features of the situation. For example:

  • the intervals in which the distance increased or stayed constant
  • how quickly the distance was increasing
  • the time when the hiker traveled the greatest distance on that hike

If we are looking at distance from the trailhead (the start of the trail) as a function of time, the graph of the function might look something like this:

A graph.

It shows the distance increasing as the hiker was walking away from the trailhead, and then decreasing as she was returning to the trailhead.

Glossary Entries

  • average rate of change

    The average rate of change of a function \(f\) between inputs \(a\) and \(b\) is the change in the outputs divided by the change in the inputs: \(\frac{f(b)-f(a)}{b-a}\). It is the slope of the line joining \((a,f(a))\) and \((b, f(b))\) on the graph.

  • decreasing (function)

    A function is decreasing if its outputs get smaller as the inputs get larger, resulting in a downward sloping graph as you move from left to right.

    A function can also be decreasing just for a restricted range of inputs. For example the function \(f\) given by \(f(x) = 3 - x^2\), whose graph is shown, is decreasing for \(x \ge 0\) because the graph slopes downward to the right of the vertical axis.

  • horizontal intercept

    The horizontal intercept of a graph is the point where the graph crosses the horizontal axis. If the axis is labeled with the variable \(x\), the horizontal intercept is also called the \(x\)-intercept. The horizontal intercept of the graph of \(2x + 4y = 12\) is \((6,0)\).

    The term is sometimes used to refer only to the \(x\)-coordinate of the point where the graph crosses the horizontal axis.

  • increasing (function)

    A function is increasing if its outputs get larger as the inputs get larger, resulting in an upward sloping graph as you move from left to right.

    A function can also be increasing just for a restricted range of inputs. For example the function \(f\) given by \(f(x) = 3 - x^2\), whose graph is shown, is increasing for \(x \le 0\) because the graph slopes upward to the left of the vertical axis.

  • maximum

    A maximum of a function is a value of the function that is greater than or equal to all the other values. The maximum of the graph of the function is the corresponding highest point on the graph.

  • minimum

    A minimum of a function is a value of the function that is less than or equal to all the other values. The minimum of the graph of the function is the corresponding lowest point on the graph.

  • vertical intercept

    The vertical intercept of a graph is the point where the graph crosses the vertical axis. If the axis is labeled with the variable \(y\), the vertical intercept is also called the \(y\)-intercept.

    Also, the term is sometimes used to mean just the \(y\)-coordinate of the point where the graph crosses the vertical axis. The vertical intercept of the graph of \(y = 3x - 5\) is \((0,\text-5)\), or just -5.
