Lesson 10

Solving Problems with Trigonometry

  • Let’s solve problems about right triangles.

10.1: Notice and Wonder: Practicing Perimeter

What do you notice? What do you wonder?

A square inscribed in a circle, radius 1 unit.
A hexagon inscribed in a unit circle.
A decagon inscribed in a unit circle.

10.2: Growing Regular Polygons

  1. Here is a square inscribed in a circle with radius 1 meter. What is the perimeter of the square? Explain or show your reasoning.

    Square inside of circle with radius =1. Distance from center of circle and square to each vertex of square =1.
  2. What is the perimeter of a regular pentagon inscribed in a circle with radius 1 meter? Explain or show your reasoning.

  3. What is the perimeter of a regular decagon inscribed in a circle with radius 1 meter? Explain or show your reasoning.

  4. What is happening to the perimeter as the number of sides increases?



Here is a diagram of a square inscribed in a circle and another circle inscribed in the same square.

diagram of square inscribed in circle and another circle inscribed in the same square. Radius of large circle = 1 unit
  1. How much shorter is the perimeter of the small circle than the perimeter of the large circle?
  2. If the square was replaced with a regular polygon with more sides, would your previous answer be larger, smaller, or the same? Explain or show your reasoning.

10.3: Gentle Descent

An airplane travels 150 miles horizontally during a decrease of 35,000 feet vertically.

  1. What is the angle of descent?
  2. How long is the plane's path?
A photo of an airplane landing

Summary

We know how to calculate the missing sides and angles of right triangles using trigonometric ratios and the Pythagorean Theorem. We can use the same strategies to solve some problems with other shapes. For example: Given a regular hexagon with side length 10 units, find its area.

Hexagon with side length = 10

Decompose the hexagon into 6 isosceles triangles. The angle at the center is \(360^\circ \div 6=60^\circ\). That means we created 6 equilateral triangles because the base angles of isosceles triangles are congruent.

hexagon decomposed into 6 isosceles triangles. angle at center = 60 degrees. Each side of hexagon = 10.


Equilateral triangle side lengths of 10 units. Altitude, labeled h, is drawn creating a right angle at the base and a 30 degree angle to the left of the altitude.

To find the area of the hexagon, we can find the area of each triangle. Drawing in the altitude to find the height of the triangle creates a right triangle, so we can use trigonometry. In an isosceles (and an equilateral) triangle the altitude is also the angle bisector, so the angle is 30 degrees. That means \(\cos(30)=\frac{h}{10}\) so \(h\) is about 8.7 units. The area of one triangle is \(\frac12(10)(8.3)\), or 43.3 square units. So the area of the hexagon is 6 times that, or about 259.8 square units.

Glossary Entries

  • arccosine

    The arccosine of a number between 0 and 1 is the acute angle whose cosine is that number.

  • arcsine

    The arcsine of a number between 0 and 1 is the acute angle whose sine is that number.

  • arctangent

    The arctangent of a positive number is the acute angle whose tangent is that number.

  • cosine

    The cosine of an acute angle in a right triangle is the ratio (quotient) of the length of the adjacent leg to the length of the hypotenuse. In the diagram, \(\cos(x)=\frac{b}{c}\).

  • sine

    The sine of an acute angle in a right triangle is the ratio (quotient) of the length of the opposite leg to the length of the hypotenuse. In the diagram, \(\sin(x) = \frac{a}{c}.\)

  • tangent

    The tangent of an acute angle in a right triangle is the ratio (quotient) of the length of the opposite leg to the length of the adjacent leg. In the diagram, \(\tan(x) = \frac{a}{b}.\)

  • trigonometric ratio

    Sine, cosine, and tangent are called trigonometric ratios.
