Lesson 1

A Different Kind of Change

  • Let’s find the rectangle with the greatest area.

1.1: Notice and Wonder: Three Tables

Look at the patterns in the 3 tables. What do you notice? What do you wonder?

\(x\) \(y\)
1 0
2 5
3 10
4 15
5 20
\(x\) \(y\)
1 3
2 6
3 12
4 24
5 48
\(x\) \(y\)
1 8
2 11
3 10
4 5
5 -4

1.2: Measuring a Garden

Noah has 50 meters of fencing to completely enclose a rectangular garden in the backyard.

  1. Draw some possible diagrams of Noah’s garden. Label the length and width of each rectangle.

    vegetable garden
  2. Find the length and width of such a rectangle that would produce the largest possible area. Explain or show why you think that pair of length and width gives the largest possible area.

1.3: Plotting the Measurements of the Garden

  1. Plot some values for the length and area of the garden on the coordinate plane.
    Blank coordinate plane. Horizontal axis, length of garden in meters, 0 to 30 by 5’s. Vertical axis, area of garden in square meters, 0 to 200 by 25’s.
  2. What do you notice about the plotted points?
  3. The points \((3,66)\) and \((22,66)\) each represent the length and area of the garden. Plot these 2 points on coordinate plane, if you haven’t already done so. What do these points mean in this situation?
  4. Could the point \((1,25)\) represent the length and area of the garden? Explain how you know.


  1. What happens to the area when you interchange the length and width? For example, compare the areas of a rectangle of length 11 meters and width 14 meters with a rectangle of length 14 meters and width 11 meters.
  2. What patterns would you notice if you were to plot more length and area pairs on the graph?

Summary

In this lesson, we looked at the relationship between the side length and the area of a rectangle when the perimeter is unchanged.

If a rectangle has a perimeter of 40 inches, we can represent the possible lengths and widths as shown in the table.

We know that twice the length and twice the width must equal 40, which means that the length plus width must equal 20, or \(\ell + w = 20\).

length (inches) width (inches)
2 18
5 15
10 10
12 8
15 5

To find the width given a length \(\ell\), we can write: \(w= 20- \ell\).

The relationship between the length and the width is linear. If we plot the points from the table representing the length and the width, they form a line.

Points plotted. Horizontal axis, length in inches, 0 to 24 by 4’s. Vertical axis, width in inches, 0 to 40 by 10’s. Points at 2 comma 18, 5 comma 15, 10 comma 10, 12 comma 8, 15 comma 5.

What about the relationship between the side lengths and the area of rectangles with perimeter of 40 inches?

Here are some possible areas of different rectangles whose perimeter are all 40 inches.

length (inches) width (inches) area (square inches)
2 18 36
5 15 75
10 10 100
12 8 96
15 5 75

Here is a graph of the lengths and areas from the table:

Points plotted. Horizontal axis, length in inches, 0 to 24 by 4’s. Vertical axis, area in square inches, 0 to 125 by 25’s. Points at 2 comma 36, 5 comma 75, 10 comma 100, 12 comma 96, 15 comma 75.

Notice that, initially, as the length of the rectangle increases (for example, from 5 to 10 inches), the area also increases (from 75 to 100 square inches). Later, however, as the length increases (for example, from 12 to 15), the area decreases (from 96 to 75).

We have not studied relationships like this yet and will investigate them further in this unit.
